Type 2041 – Control head
The compact control head type 2041 is an intelligent position indicator for linear valves with an integrated pilot valve and was specially developed for industrial applications with high requirements for process reliability and operating convenience. It offers a reliable feedback of the valve position, both visually by means of coloured high-visibility LEDs and electrically in real-time via digital output signals.
Thanks to its maintenance-free position detection, the control head is ideal for use in the chemical, pharmaceutical, food, water, and wastewater industries. It operates reliably within a temperature range of –4 °F to +140 °F. The rugged housing design with IP65 or IP67 protection per EN 60529 ensures safe operation even in humid, dirty, or otherwise harsh environments.
| Connection |
Electrical connection via M12 connector in accordance with DIN EN 60529 |
| Application |
Intelligent position indicator for linear valves with an integrated pilot valve |
| Nominal stroke |
0.08 inch - 1.18 inch |
| Protection class |
IP67 |
| Adjustment of stroke and zero point |
Self-adapting |
| Versions |
3 interfaces 24V, AS-i, IO-Link, each with solenoid valve 3 different sensing pin lengths |
| Supply |
24 V DC |
| Temperature range |
-4 °F to +140 °F |
| Air in |
max. 116 psi |
| Approvals, certificates and declarations |
EC Declaration of Conformity UKCA Declaration of Conformity |
| For details, see the documentation or upon request. | |
